TTW04 Classic - Through the Wall Wine Cellar Cooling Unit - 50Hz
$4,950.00
The Wine Guardian TTW04 Classic Series offers essential wine cellar cooling at an exceptional value. With a standard plug connection and simplified design, this unit offers precise temperature control and effortless installation for indoor use.
-
Description
The Wine Guardian Classic Series Through-the-Wall Cooling Unit is designed for the value-conscious wine collector who wants reliable performance without unnecessary extras. This streamlined system delivers precise temperature control to protect your collection, while maintaining a simple, user-friendly design.
The TTW01F, G, I, and J are 50 Hz units, which is standard in the majority of Europe, Asia, Africa, Australia, & New Zealand. Unit capacity is up to 1.101kW.
Please note: this unit is not rated for exterior use and should be installed in an interior through-the-wall application only. This unit is NOT compatible with humidifiers.
Additional information
| Weight | 71 lbs |
|---|---|
| Dimensions | 25.8 × 14.1 × 15.75 in |
| Model | TTW04 Classic |
| Capacity | 1.101 kW @ 24ºC. If you have different condensing side conditions, check our spec sheet for performance. |
| Line Frequency | 50 Hz |
| Ductless/Ducted | Ductless |
| Where to Buy | Distributor, Online |
| Plug Type | Plug Type F, Plug Type G, Plug Type I, Plug Type J |
| Installation Level | Do-It-Yourself |
| Sound | 61.0 dBA |
| Length | 66 cm |
| Width | 36 cm |
| Height | 40 cm |
| Weight | 32.2 kg |
| Electrical | 240/1/50 |
| Notable Features | Bluetooth / NFC Controls, Extended Temperature Control Range |
Documents and Resources
| Resource Name | |
|---|---|
|
|
TTW Product Brochure |
|
|
TTW Spec Sheet 50 Hz |
|
|
TTW Quick Start Installation Guide |
Standard Options
Serving Temperature
Allows the system to control to an extended temperature range from 42°F to 64°F (5°C to 18°C). This option is ideal for single to multiple cabinet applications and small wine rooms where consumption-temperature cooling is preferred. It also allows the user to rotate wine stock and change set point from season to season, making it ideal for restaurants, wine bars, clubs, etc.
Available Options
This product has no optional features.
